LIFTING CONVEYOR OVERVIEW
Conveyor lifting solutions are helping freight with higher weight that other devices can not meet. Contribute to solving the difficult takes a lot of manpower and effort of many businesses. The most common is lifting up the vehicle, or lifting up high positions in factories, warehouses factories ...
Conveyors are designed to be able to lift two-way cargo from containers in the car, truck, warehouse down or from the bottom, the car factory, used to organize the packaging material into the stack higher shipments to each other that people can hardly undertake.
Maybe mobile thanks wheel systems, operate independently or in conjunction with other transport devices create the flexibility of the system.
Thanks to these advantages conveyors Cheap lifting for your business will help reduce manpower, automated production lines thereby increasing productivity and the cost of the initial investment will significantly save other solutions.

COMPOSITION LIFTING CONVEYOR
Frame of the conveyor system are typically raised and lowered repeatedly combined with the weight of the cargo requires 2 frames to ensure key elements are light and rigid. To meet that requirement Buoc Tien use reinforced steel frame support bearing bars to fabricate conveyor frame to minimize the deviation of the conveyor. Surface covered with powder coated frame. width from 400-1200 (mm).
Flexible lifting height is adjusted by motor winch or hydraulic lifting terrain matching product freight.
Ben lifting system hydraulic, winch lifting of long reputed firms in addition we can manufacture hand winch lifting to reduce the cost price.
The most effective elevation angle from (0-300).
Conveyor belt surface should be rough lifting or ribbed to increase the friction, improve product adhesion when shipping high. Also need to coordinate with other devices such as the inverter to adjust the speed, structure safety, emergency switch to prevent the occurrence of incidents and technical standards to ensure safe lifting.
Funeral Funeral active and passive is made of seamless steel pipes to ensure concentricity, reducing vibration during operation.
Wire rollers: Made of high-precision steel tubes ensure the rollers with vibration and noise low friction coefficient, waterproof, effective sealing system.

ADVANTAGE
Conveyors can lifting cargo volume and different sizes on a product typically is less than 50kg.
Ability to low power consumption.
Conveyor lifting maneuverability with firm structure, easy maintenance, reliable and effective cost savings.
Productive activity and long-term durability. Reduce the cost of human resources and initial investment.
Widely used to transport materials or granular products that are packaged in a variety of industries, such as agriculture, mining, metallurgical, coal and construction dung..vv

SPECIFICATIONS - CONVEYOR LIFTING RATES
Wire width: 300mm, 400mm option, 450mm, 500mm, 600mm, 700mm, 800mm ...
Conveyor length: 2.5 m, 3 m, 4 m, 5 m, 6 m, 8 m ...
Lifting Height: 1-5 m ... ability to change the height of flexibility.
Type conveyor belt: Rubber cords bearing veins V 8-12 mm thickness suitable for heavy load and improve the high altitude, PVC wire suitable lightweight cargo 3-5 wire thickness (mm).
Lifting equipment: hand operated winch, winch motor control, hydraulic control.
The ability to download: 30-100 (kg / m).
Motor power (2.2-5.5) (kw).
Conveyor belt speed: 10-20 (m / min).
Conveyor frames: made of stainless steel materials, steel
Lifting conveyor prices: contact
