Conveyor rollers navigation

Code : BT13

Prices : Contact

Hotline : 0918 913 146
Decription product

Conveyor rollers are suitable solutions to transport products from light weight, moderate to severe, in normal environments to environments with corrosive chemicals, dust ...

The structure of the conveyor roller conveyor consists of frame, Turnbuckle structure, edge products sure to not fall out and the important part it's rollers. So quality requirements are always at the forefront to ensure durable roller and efficient use.

Roller conveyors used appropriately to move the plane products like hard bottom container, carton, pallet frame with the cost advantages of investment, lower operation and maintenance, always in the first selection the first enterprise system for the design of the product conveyor.

ROLLER CONVEYORS FABRICATION:

- System of conveyor roller frame is made of steel, or stainless steel, designed to be easy to remove and easy to move. In addition to meeting the requirements of Freight Our lightly apply the most optimal solution at present is to use shaped aluminum frame.
- The axis of the rollers used seamless steel pipes or stainless steel.
- Materials can fabricate steel rollers, stainless steel, plastic ...
- Surface roller galvanized, coated rubber or reinforced plastic wrap, etc.
- The type of roller conveyors are used for include: roller straight, taper roller, roller auto adjustment, stainless steel rollers, plastic rollers ...

STRUCTURES IN THE ROLL:

- Two roller shaft is machined beveled edges, milling, tapping holes, threaded bolted or run according to the purpose and application attached to the conveyor frame.
- Pipe rollers are machined surfaces ensure accurate concentricity and beveled
- Bearings: use genuine bearings achieve durability, payload.
- The system protects bearings Felt: Guarantee for high rollers and active life working in areas where there is moisture, dust environment, abrasive rust ...
- Roller our cost savings on repair and maintenance of the conveyor by concentric design, reduce vibration.

ROLLER CONVEYORS ADVANTAGES:

- Simple structure, cost is not high compared with other conveyor belts are effective solutions improve production capacity for businesses.
- Low friction coefficient, waterproof and dust, effective sealing system
- High precision steel pipes ensure the rollers operate with low vibration and noise.
- Robust ensure long life, stable and good quality.
- Attractive prices.

SPECIFICATION SCOPE ROLLER CONVEYORS:

- Length of conveyor rollers: 1000-20000 (mm).
- Height: 400-1200 (mm).
- Width: 190-2500 (mm).
- Roller Diameter: o34 deno 219 (mm).
- Length of roller: 190-2, 500 (mm).
- Roller Thickness: 1.5 - 10 (mm).
- Distance 2 rollers: 80, 100, 120, 150, 180 (mm) ...
- Frame Material: Steel, powder coated surfaces, stainless steel frame.
